Epson® EB-PQ2220B 20,000-Lumen 4K 3LCD Laser Projector

SKU V11HB05820
$ 0.00
$ 0.00
Buy itPrice on request Tell us about your production and we'll email you a price. Request pricing →Speak with a projection specialist
Buying for a school? Request a quote

How school ordering works

  • Purchase orders from U.S. public schools
  • Formal quotes & tax-exempt orders
  • Systems racked & tested before they ship
  • Theatre specialists 718-874-2642

Setup & Troubleshooting

Visit the Stage Gear Help Center

Epson EB-PQ2220B 20,000-Lumen 4K 3LCD Laser Projector Epson EB-PQ2220B 20,000-Lumen 4K 3LCD Laser Projector – view 2 Epson EB-PQ2220B 20,000-Lumen 4K 3LCD Laser Projector – view 3 Epson EB-PQ2220B 20,000-Lumen 4K 3LCD Laser Projector – view 4
Epson EB-PQ2220B 20,000-Lumen 4K 3LCD Laser Projector Epson EB-PQ2220B 20,000-Lumen 4K 3LCD Laser Projector – view 2 Epson EB-PQ2220B 20,000-Lumen 4K 3LCD Laser Projector – view 3 Epson EB-PQ2220B 20,000-Lumen 4K 3LCD Laser Projector – view 4

Sold by Stage Gear LLC. Stage Gear is an Authorized Reseller of Epson® products. Ships within the United States.

5-year Epson coverage available · ShowCare eligible Speak with a projection specialist

Quick specifications

Brightness20,000 lumens color / 20,000 lumens white
Resolution1080p with 4K Crystal Motion (1920 x 1080 x 4) (4K UHD on screen)
Light sourceLaser Phosphor
Light source life20,000 hours (Normal Mode); 30,000 hours (Extended Mode)
ContrastUp to 5,000,000:1 (Dynamic Contrast: On)
Lens shiftVertical ±60%, horizontal ±18%
LensInterchangeable, sold separately
Weight64.3 lb
Key connections12G-SDI In/Out, HDMI (HDCP 2.3) x 2 / HDMI Out x 1, HDBaseT x 1, USB Type-B x 1, USB Type-A x 2, USB Type-A for Wireless LAN (optional), Serial RS-232c x 1, Network RJ-45, Variable Audio Out (Mini Stereo) x 1
Part numberV11HB05820
Manufacturer warrantyThree-year limited or 20,000 hours, whichever comes first, in the U.S. and Canada

Specifications are from the manufacturer's published specification sheet. Specifications are subject to change by the manufacturer.

Protection plan

Cover your EB-PQ2220B for up to 5 years

Your projector includes Epson's 3-year warranty. Add an Epson Preferred Plus plan to your quote to extend it.

Yr 1Included
Yr 2Included
Yr 3Included
Yr 4With plan
Yr 5With plan

3-year Epson limited warranty, return for repairAdded by the planCovered by Epson through year 5.

Buy within 90 days of the projector. Easiest: add it to the same quote.

Choose your coverage
Add 5-year coverage to my quote How Epson plans work →
Plan details

Plans are sold by Stage Gear, an Authorized Epson Reseller, and provided by Epson America under Epson's service plan terms; coverage details vary by model. Epson and Epson Preferred are trademarks of Seiko Epson Corporation and Epson America, Inc. Full plan terms: epson.com/esp.

ShowCare for Projection

Epson covers the repair.
ShowCare covers the show.

If your projector goes in for a covered repair, we ship you a replacement from our rental stock so the show goes on.

  • 1, 2 or 4 weeks of replacement projector per year at no cost.
  • Works with your lens. The closest model we have in stock.
  • We handle the Epson claim and the return for repair for you.
  • Longer repair? Extra weeks at 50% of our rental rate, up to 8 weeks per repair.
From $995per projector, per year
Needs 5 years of Epson coverage. Pair it with the 5-year Epson plan.
Choose ShowCare coverage How ShowCare works
Stage Gear editorial guidance

Stage Gear Take

Built for big images and big houses. We will help plan mounting, signal and lens choice before you commit.

Best for
Large venues, wide cyc and full-stage scenic projection, longer throws and bright stage lighting.
Why we like it for theatre
20,000 lumens of equal color and white brightness; a laser light source, so no lamps to change mid-run; interchangeable powered lenses for booth, catwalk or short-throw positions; 4K UHD on screen via 4K Crystal Motion, a good fit if your scenic content is produced in 4K; 12G-SDI for long cable runs from the booth.
Consider another model if
Your room is mid-size or budget is the priority, where a 7,000–10,000-lumen model often does the job. These are heavier units, so plan mounting and rigging with us.

This is Stage Gear's own guidance, not a manufacturer claim. Every venue is different; ask us to confirm it fits yours.

Lenses that work with this projector

This projector ships without a lens. These lenses are listed by the manufacturer as compatible; throw ratios shown are for this projector.

ELPLX02S Ultra Short-throw Lens for Epson® Pro Series ProjectorsELPLX02SUltra short throw (fixed)Throw ratio: 0.34 (fixed)View details → Epson® Short-throw #1 Zoom Lens ELPLU03SELPLU03SShort-throw zoomThrow ratio: 0.46–0.56View details → Epson® Short Throw #2 Zoom Lens (ELPLU04)ELPLU04Short-throw zoomThrow ratio: 0.62–0.75View details → Epson® Wide-Throw #2 Zoom Lens (ELPLW06)ELPLW06Wide-throw zoomThrow ratio: 1.15–1.57View details → Epson® Wide-Throw #3 Zoom Lens ELPLW08ELPLW08Wide-throw zoomThrow ratio: 0.83–1.17View details → Epson® Middle-Throw Zoom Lens #2 (ELPLM15)ELPLM15Middle-throw zoomThrow ratio: 1.52–2.47View details → Epson® Middle-Throw Zoom Lens #3 (ELPLM10)ELPLM10Middle-throw zoomThrow ratio: 2.34–3.59View details → Epson® Middle-Throw Zoom Lens #4 (ELPLM11)ELPLM11Middle-throw zoomThrow ratio: 3.42–5.23View details → Epson® Long Throw Zoom Lens (ELPLL08)ELPLL08Long-throw zoomThrow ratio: 5.09–7.16View details →

Not sure which throw ratio you need? Throw ratio = distance to screen ÷ image width. Send us your measurements and we'll pick the lens.

Compare projectors Not sure this fits your venue? Complete your system Stage Gear Rental Protection Shop all projectors

Sold by Stage Gear LLC, 47 Main Street South, Woodbury, CT 06798 · 718-874-2642 · hello@shopstagegear.com. Stage Gear is an Authorized Reseller of Epson® products. Purchases made through this website are transactions with Stage Gear, not Epson, and are subject to Stage Gear's shipping and return, refund and exchange policies. Epson® products ship only to addresses in the United States. Epson is a registered trademark of Seiko Epson Corporation.

The EB-PQ2220B is a compact 20,000-lumen 3LCD laser projector with equal white and color brightness and Epson's 4K Crystal Motion technology for large venues.

  • Brightness: 20,000 lumens color / 20,000 lumens white
  • Resolution: 1080p with 4K Crystal Motion (1920 x 1080 x 4) (4K UHD on screen)
  • Light source: Laser Phosphor, 20,000 hours (Normal Mode); 30,000 hours (Extended Mode)
  • Lens: interchangeable, sold separately
  • Key connections: 12G-SDI In/Out, HDMI (HDCP 2.3) x 2 / HDMI Out x 1, HDBaseT x 1, USB Type-B x 1, USB Type-A x 2, USB Type-A for Wireless LAN (optional), Serial RS-232c x 1, Network RJ-45, Variable Audio Out (Mini Stereo) x 1
  • Weight: 64.3 lb

Specifications are from the manufacturer's published specification sheet. Sold by Stage Gear LLC, an Authorized Reseller of Epson® products. Pricing is provided by quote and configured with the lens and accessories your venue needs.
